PRODUCT PARAMETERS

High Efficiency: The self-driving feature allows the machine to move quickly within the worksite, significantly enhancing work efficiency.

Ease of Operation: Equipped with a simple operating system, it enables operators to quickly learn and master its use.

Stability and Safety: The sturdy scissor structure and reliable safety systems, including anti-fall devices and emergency stop buttons, ensure operational safety.

Adaptability: Its compact design enables it to operate in narrow spaces, making it suitable for various work environments.

Economical and Environmental: Typically powered by electric systems, which not only reduce energy consumption but also help minimize noise and emissions during operation.

REQUEST A QUOTE

Description

FAQs

Request A Quote

Description

Model (Self-propelled Electric Scissor Lift)	ADGTJZ05	ADGTJZ04	ADGTJZ03
Maximum Working Height	7.6m	6.0m	5.0m
Maximum Platform Height	5.6m	4.0m	3.0m
Main Platform Capacity	230kg	230kg	260kg
Extension Platform Capacity	100kg	100kg	100kg
Platform Dimensions (L×W×H)	1.39 × 0.716 × 1.13m	1.29 × 0.716 × 1.13m	1.29 × 0.716 × 1.13m
Machine Dimensions without Guardrail (A×B×C)	1.51 × 0.85 × 2.14m	1.43 × 0.76 × 2.04m	1.43 × 0.76 × 1.95m
Machine Dimensions with Guardrail (A×B×C)	1.51 × 0.85 × 1.73m	1.43 × 0.76 × 1.64m	1.43 × 0.76 × 1.55m
Extension Platform Size	0.6m	0.6m	0.6m
Minimum Ground Clearance	0.07 / 0.015m	0.07 / 0.015m	0.07 / 0.015m
Guardrail Height	1.123m	1.058m	1.058m
Turning Radius (Inner/Outer)	0.5/1.73m	0.4/1.6m	0.4/1.6m
Battery Motor	24V/0.8kw	24V/0.8kw	24V/0.8kw
Lifting Speed	6~9m/min	6~9m/min	6~9m/min
Drive Motor	2 × 0.5kw / 24V	2 × 0.4kw / 24V	2 × 0.4kw / 24V
Driving Speed (Fast Mode)	4km/h	4km/h	4km/h
Driving Speed (Cruise Mode)	0.8km/h	0.8km/h	0.8km/h
Battery Capacity	2 × 12V/100ah	2 × 12V/80ah	2 × 12V/80ah
Charger	24V/15A	24V/10A	24V/10A
Maximum Climbing Ability	25%	25%	25%
Maximum Permissible Angle	1.5° / 3°	1.5° / 3°	1.5° / 3°
Tires	φ230 × 100mm	φ230 × 80mm	φ230 × 80mm
Weight	970kg	850kg	800kg

FAQs

What types of products can we offer?

As an ISO 9001-certified manufacturer of elevation equipment, we specialize in engineered lifting solutions including：Scissor Lifts (EN 1570 compliant, 2-18m lift height),Boom Lifts (Articulating/Telescopic, 360° rotation capability),Fixed Scissor Platforms (Customizable up to 30T static load),Vehicle Turntables (Hydraulic drive, Ø5-15m configurations),Dock Levelers (Fixed/Mobile types, EN 1398:2017 certified),Guided Freight Elevators (Mast-guided rail system, 500-3000kg capacity)

What logistics do we ship through?

Can it be customized as per our requirements?

What is our ordering process?

Our ordering process initiates with precise product specification confirmation through CAD drawing approvals, followed by a 30% advance payment via secure international transfer channels (TT/LC/SWIFT accepted), which triggers production commencement within 24 hours of payment verification. The remaining 70% balance must be settled prior to bill of lading issuance, ensuring full compliance with INCOTERMS 2020 regulations and seamless cargo release from origin ports.

What services are included in the after-sales service?
